Flexible and halogen free (LSHF) power cable for public places.
Toxfree® ZH Z1Z1-K (AS) is a LSHF safety cable. In the event of fire, it does not emit toxic gases, nor does it give off corrosive gases, avoiding any possible damage to people or electronic equipment. For these reasons it is highly recommended for use in public places such as: hospitals, schools, museums, airports, bus terminals, shopping malls, offices, laboratories, etc.
TOXFREE® ZH Z1Z1-K (AS) cable performance
Electrical performance
LOW VOLTAGE 0,6/1 kV
Standard
IEC 60502-1 / UNE 21123-4
Approvals
CE / RoHS
CPR Construction Products Regulation
B2ca -s1a, d1, a1
Thermal performance
Maximum service temperature: 70°C.
Maximum short-circuit temperature: 160ºC (máximo 5 s).
Minimum service temperature: -40ºC (static, with protection).
Fire performance
Flame non-propagation according to EN 60332-1 / IEC 60332-1.
Fire non-propagation according to EN 60332-3 / IEC 60332-3 and EN 50399.
LSHF (Low Smoke Halogen Free) according to EN 60754-1 / IEC 60754-1
Low smoke emission according to EN 61034 / IEC 61034: Light transmittance > 80%.
Low corrosive gases emission according to EN 60754-2 / IEC 60754-2.
Reaction to fire CPR, B2ca -s1a, d1, a1 according to EN 50575.
Mechanical performance
Minimum bending radius: 5x cable diameter.
Impact resistance: AG2 Medium severity.
Environmental performance
Chemical & Oil resistance: Acceptable.
UV Resistant: UNE 211605 and EN 50618. Water resistance: AD5 Jets.
Installation conditions
Open Air. Buried. In conduit.
Aplications
Industrial use. Public places.
TOXFREE® ZH Z1Z1-K (AS) cable design
Conductor
Electrolytic annealed copper conductor class 5 (flexible) according to EN 60228 and IEC 60228.
Insulation
Special low smoke and halogen free polyolefin insulation. The standard identification of insulated conductors according to HD 308 is the following:
6G or more Black numbered + Green/Yellow.
Outer sheath
Low Smoke Halogen Free (LSHF) polyolefin outer sheath, not toxic and fire retardant. Green colour. Other outer sheath colours available on request.
Fire non-propagation based on EN 60332-3 / IEC 60332-3 / EN 50399.
Maximum service temperature: 70ºC.
Public places.
CE
IEC 60502-1 / UNE 21123-4
B2ca s1a, d1, a1
Impact resistance: AG2 Medium severity.
✔ Chemical & Oil resistance: Acceptable.
✔ UV Resistant according to EN 50618.
✔ Fire non-propagation based on EN 60332-3 / IEC 60332-3 / EN 50399.
✔ Flame non-propagation based on EN 60332-1 and IEC 60332-1
✔ Halogen free based on EN 60754-1
✔ Low corrosive gases emission based on UNE-EN 60754-2 and IEC 60754-2.
✔ Low smoke emission according to EN 61034 and IEC 61034: Light transmittance > 80%.
✔ Impact resistance: AG2 Medium severity.
✔ Minimum bending radius: x5 cable diameter.
✔ LOW VOLTAGE 0,6/1kV
✔ Maximum service temperature: 70ºC.
✔ Maximum short-circuit
✔ temperature: 160ºC (max. 5 s).
✔ Minimum service temperature: -40ºC.
✔ Water resistance: AD5 Jets.
✔ B2ca s1a, d1, a1
✔ Buried.
✔ In conduit.
✔ Open Air.
✔ CE
✔ RoHS
✔ IEC 60502-1 / UNE 21123-4
✔ Industrial use.
✔ Public places.
1. Conductor
Electrolytic annealed copper conductor class 5 (flexible) according to EN 60228 and IEC 60228.
2. Insulation
Special low smoke and halogen free polyolefin insulation. The standard identification of insulated conductors according to HD 308 is the following:
6G or more Black numbered + Green/Yellow
3. Outer sheath
Low Smoke Halogen Free (LSHF) polyolefin outer sheath, not toxic and fire retardant. Green colour. Other outer sheath colours available on request.
